667HD Full Mortise Aluminum Continuous Hinges
Templates are arranged in order by size, smallest to largest. Click on the blue link of the template you wish to download or view. For cut sheet information on the Aluminum Continuous Hinges, click here to visit the catalog.
For FAQ's please click here.
|
667 – Standard Duty for flush door and frame applications 667 HD – Heavy Duty for flush door and frame applications |
 |
| Hinge | Size | Template | Description | Rev | Last Updated |
| 667HDLL | All Sizes | T91664 | 667HDLL - Aluminum Geared Hinge, 1/8" Inset Full Concealed with Cut-Out for School Cap Ligature Resistant Bearing |
B | 2021 |
| 667HDWTLL | All Sizes | T91665 | 667HDWTLL - Aluminum Geared hinge, Wide Throw, 1/8" Inset, Full Concealed. Hinges are supplied with Lead-Lined Mounting Holes for Additional Support Standard |
B | 2021 |
| 667HD | All Sizes | T91640 | 667HD - (CS) Concealed Switch |
B | 2021 |
| 667HD | All Sizes | T91641 | 667HD - (CE-12) 12 Wire Easy Access With Removable Option |
B | 2021 |
| 667HD | All Sizes | T91642 | 667HD - (CE-12) 12 Wire Easy Access |
B | 2021 |
| 667HDLL | All Sizes | T91693 | 667HDLL Installation Instructions |
B | 2021 |
