661HD Full Mortise Aluminum Continuous Hinges
Templates are arranged in order by size, smallest to largest. Click on the blue link of the template you wish to download or view. For cut sheet information on the Aluminum Continuous Hinges, click here to visit the catalog.
For FAQ's please click here.
|
661 HD – Heavy Duty for flush door and frame applications |
 |
| Hinge | Size | Template # | Template | Rev | Last Updated |
661 HD, HDLL |
All Sizes | T92542 | Aluminum Geared Hinge, Full Mortise | B | 2021 |
|
|
All Sizes | T91659 | Aluminum Geared Hinge Wide Throw, Flush Mount, Full Concealed |
B | 2021 |
661 WTHDWTLL |
All Sizes | T91695 | Aluminum Geared Hinge Wide Throw, Flush Mount, Full Concealed |
B | 2021 |
661HD CE |
All Sizes | T91637 | T91637 661HD CE 12 Wire Easy Access W/Removable Option |
B | 2021 |
661HD CE |
All Sizes | T91638 | T91638 661HD CE 12 Wire Easy Access |
B | 2021 |
661HD CS |
All Sizes |
T91639 661HD CS |
B |
2021 |
|
661 HD |
All Sizes |
661HD, 662, HD, 663 HD |
B |
2021 |
|
661 HD |
All Sizes | T91693 |
Installation Instructions |
B |
2021 |
