Click on the Template ID to open the template you wish to view. For installation instructions, click on the drawing number you wish to open.
Templates/Technical Drawings
|
Template ID |
Description |
Last Updated |
Rev |
| T91623 | C200 Lever for Wood or Metal Doors | 10/2021 | A |
| T91624 | C200 Cylindrical Locks w/RQE Backset: 3-3⁄4" [95 mm] and 5" [127 mm] |
10/2021 | A |
| T91628 | C200 Dummy Trim | 10/2021 | A |
| T91617 | C100-1-1/8" Face Plate Backset: 3-3/4" [95 mm] |
10/2022 | A |
| T91618 | C200 Wood Doors with 1-1/8" Face Plate Backset: 3-3/4" [95 mm] |
10/2022 | A |
| T91619 | C200 Metal Doors with 1-1/8" Face Plate Backset: 5" [127 mm] |
10/2022 | A |
| T91620 | C200 Wood Doors with 1-1/8" Face Plate Backset: 5" [127 mm] |
10/2022 | A |
| T91626 | C200 Metal Doors with 1-1/8" Face Plate Backset: 2-3/4" [70 mm] |
10/2022 | A |
| T91627 | C200 Wood Doors with 1-1/8" Face Plate Backset: 2-3/4" [70 mm] |
10/2022 | A |
| T91632 | C200 Metal Doors with 1-1/8" Face Plate Backset: 2-3/8" [60 mm] |
10/2022 | A |
Installation Instructions | |||
| T91907 | C200 Cylindrical Lock | 10/2021 | A |
Strike Templates/Technical Drawings | |||
| T91622 | 5001 Strike Metal Jamb | 10/2022 | A |
| T91829 | 2101 Strike Metal/Wood Jamb | 10/2022 | A |
