4/6 SERIES ELECTRIC STRIKES TEMPLATES AND INSTRUCTIONS |
BES-4105U (fail secure 12VAC/VDC)
BES-4108U (fail secure 24VAC/VDC)
BES-4306U (fail safe 12 VDC)
BES-4309U (fail safe 24 VDC)
BES-F41045 (Fire-Rated Centerline Strike Fail Secure 04 Faceplate 12VAC/VDC)
BES-F41048 (Fire-Rated Centerline Strike Fail Secure 04 Faceplate 12VAC/24VDC)
BES-F41145 (Fire-Rated Centerline Strike Fail Secure 14 Faceplate 12VAC/12 VDC)
BES-F41148 (Fire-Rated Centerline Strike Fail Secure 14 Faceplate 12VAC/24VDC)
BES-S65U (Standard Profile Universal - Multiple face plates)
BES-L65U (Low Profile Universal - Multiple face plates)
BES-S65ULMKM (Standard Profile Universal - Multiple face plates - Latch and Keeper Monitoring)
BES-L65ULMKM (Low Profile Universal - Multiple face plates - Latch and Keeper Monitoring)
Templates
Click on the blue drawing numbers below to download the installation instructions.
| Drawing Number | Description | Rev |
Last Updated |
| A89075 | BES-S65 Tape on Template for use with a 1-3/4" Door | B | 2021 |
Installation Instructions
| Drawing Number |
Description | Rev | Last Updated |
| A89078 | BES-4105U, BES-4108U, BES-4306U, BES-4309U Installation Instructions for Wood, Hollow Metal and Aluminum frames. | B | 2021 |
| R0615 | BES-F41045, BES-F41048, BES-F41145, BES-F41148 Installation Instructions for Aluminum & Hollow Metal frames. | A | 2015 |
| A89076 | BES-L65(LMKM) & BES-S65(LMKM) Installation Instructions for wood, aluminum and hollow metal frames. | B | 2021 |
4 Series Electric Strike Specifications
6 Series Electric Strike Specifications
ADDITIONAL INFORMATION
Electric Strike Compatibility Chart
